Brand New Shantui SD32 Bulldozer

Operating Weight: 39,700 kg

Engine Power:257 kW (344 hp)

Overall Dimensions: 8,650×4,130×3,760 mm


Explore the Shantui SD32 crawler bulldozer with 257 kW Cummins power, 10.0 m3 blade, and 39.7-ton strength for mining and earthmoving.
Get a Quote
Brand New Shantui SD32 Bulldozer

Product Overview


The Brand New Shantui SD32 is a heavy-duty 39.7-ton crawler bulldozer built for heavy earthmoving, open-pit mining, quarrying, and large-scale infrastructure projects. Powered by a high-torque Cummins engine producing 257 kW @ 2,000 rpm , the SD32 integrates Shantui's self-developed drive system and heavy-duty chassis undercarriage. Outfitted with a standard 10.0 m³ straight-tilting blade , a 3,150 mm ground contact track length, and high ground clearance, this machine delivers massive drawbar pull, deep blade penetration, and high passability in tough clay, rock, and frozen soils.


SD32 Bulldozer


Key Product Features


  • High-Power Cummins Powertrain: High-output 257 kW Cummins engine paired with Shantui's self-developed transmission and undercarriage for maximum traction and drawbar efficiency.

  • Large Capacity Dozing Blades: Supports a high-cutting-force straight-tilting blade (10.0 m³ capacity) alongside Angle (4.8 m³) and Semi-U (9.0 m³) options for heavy rock pushing and mass earthmoving.

  • Ergonomic Hexahedral Cab: Spacious 6-sided cab design offering low operator fatigue, noise reduction, and wide line-of-sight visibility across the blade corners.

  • Convenient Serviceability Layout: Wide-opening side engine guards with logically grouped filter and hydraulic component locations for quick daily servicing.


Technical Specifications


ParameterStandard Specification
Operating Weight39,700 kg
Rated Power / Speed257 kW @ 2,000 rpm
Overall Dimensions (L × W × H)8,650 × 4,130 × 3,760 mm
Engine BrandCummins
Emission StandardEU Stage II
Blade Capacity10.0 m³ (Straight Tilting) / 9.0 m³ (Semi-U) / 4.8 m³ (Angle)
Available Blade TypesStraight Tilting, Semi-U, Angle Blade
Ground Contact Length3,150 mm
Track Center Distance2,140 mm
Track Shoe Width Options560 / 610 / 660 / 710 mm
Fuel Tank Capacity640 L


EC9DD94E01BB6193BC635B9FF97E3DB2

FAQ

A:

All brand-new bulldozers come with a standard manufacturer's warranty, typically covering 12 months or 2,000 operating hours, whichever comes first. Extended warranty coverage for core components—such as the engine, main hydraulic pump, transmission, and final drive—is available upon agreement.

A:

Bulldozers are heavy-duty machines; depending on their size and weight, we employ the following safe and cost-effective shipping solutions:

Flat Rack Container: Suitable for small to medium-sized bulldozers; they can be loaded as complete units or with the blade removed.

Ro-Ro (Roll-on/Roll-off) Ship: Equipment is driven directly onto and off the vessel. Transport takes place entirely within the cargo hold, offering protection against moisture and rust, as well as the highest level of safety.

Breakbulk Ship: Suitable for bulk shipments of bulldozers or for ultra-heavy mining bulldozers (e.g., those exceeding 320 horsepower).

Containerized Transport (40HQ): Certain small to medium-sized models can be loaded into 40-foot High Cube containers after the removal of the cab, track frames, and blade, significantly reducing shipping costs.

A:

Depending on operational requirements, the following attachments can be installed on the rear of a bulldozer:

Single-Shank Ripper: Suitable for breaking up hard rock, frozen ground, or damaged pavement.

Multi-Shank Ripper: Suitable for excavating soil and shale of moderate hardness.

Winch: Suitable for forestry operations, field recovery, and towing heavy loads.

Drawbar: Used for towing other unpowered construction equipment or trailers.

A:

We can configure the optimal machine based on your specific working environment:

Machine Versions: Available in Standard (general earthmoving), Wetland/LGP (swampy and soft terrain), Desert (high-temperature and dust-resistant), and Sanitation (landfill) versions.

Blade Types: Options include the Straight-Tilt Blade (high digging force; suitable for hard soil and rock), Angle Blade (adjustable angle; suitable for road construction and trench backfilling), or Semi-U Blade (high capacity; suitable for high-volume dozing).

A:

Yes, we guarantee that all bulldozers we supply are 100% brand-new, original equipment. They undergo rigorous factory quality inspections prior to shipment and come with the original manufacturer's certificate of conformity, factory inspection report, and technical documentation.

A:

We supply brand-new bulldozers from globally renowned brands such as SHANTUI, SDLG, XCMG, SANY, and LIUGONG.
Our product lineup covers a full range of crawler bulldozers—from 80 hp to 900 hp and above—including light-duty municipal models, medium-duty general-purpose models (such as the popular 160 hp, 220 hp, and 320 hp units), and heavy-duty mining-grade models.
