SHANTUI

Explore durable bulldozer options for construction and earthmoving projects. Built for power, stability, and efficient site performance.

Brand New Shantui SD16 Bulldozer

Operating Weight: 16,400 kg

Engine Power:131 kW (175 hp)

Overall Dimensions: 5,140×3,455×3,032 mm


Explore the new Shantui SD16 medium crawler bulldozer with 131 kW power, 16.4-ton weight, and reliable performance for earthmoving jobs.
Get a Quote
Brand New Shantui SD16 Bulldozer

Product Overview


The Brand New Shantui SD16 is a versatile 16.4-ton medium crawler bulldozer designed for earthmoving, road construction, farmland leveling, and mining applications. Powered by a high-torque Weichai WD10G178E25 engine delivering 131 kW @ 1,850 rpm, the SD16 features Shantui's self-manufactured powertrain and heavy-duty chassis system. Outfitted with a standard straight-tilting blade , high ground clearance, and an ergonomic hexahedral cab, this machine delivers strong cutting force, high transmission efficiency, and smooth stability across clay, sandy soil, and frozen ground.


SD16 Bulldozer


Key Product Features


  • Matched Powertrain & High Efficiency: Weichai WD10G178E25 engine aligned with Shantui's self-developed drive system and undercarriage  for maximum drawbar pull and durability.

  • High-Penetration Blade Options: Features a high-cutting-force straight-tilting blade (3.2 m³) with an optional U-shaped blade (4.8 m³) for larger material moving volume.

  • Ergonomic Hexahedral Cab: Spacious 6-sided cab layout with comfortable operator positioning, low interior noise, and clear all-around visibility.

  • Easy Ground-Level Maintenance: Wide-opening side engine guard with logically organized filter elements for effortless daily inspections and servicing.


Technical Specifications


ParameterStandard Specification
Operating Weight16,400 kg
Rated Power / Speed131 kW @ 1,850 rpm
Overall Dimensions (L × W × H)5,140 × 3,455 × 3,032 mm
Engine Brand & ModelWeichai WD10G178E25
Emission StandardEU Stage II
Blade Capacity3.2 m³ (Straight Tilting) / 4.8 m³ (U-Shaped)
Available Blade TypesStraight Tilting, U-Shaped
Ground Contact Length2,430 mm
Track Center Distance1,880 mm
Track Shoe Width Options510 / 560 / 610 mm
Fuel Tank Capacity315 L
EC9DD94E01BB6193BC635B9FF97E3DB2

FAQ

A:

All brand-new bulldozers come with a standard manufacturer's warranty, typically covering 12 months or 2,000 operating hours, whichever comes first. Extended warranty coverage for core components—such as the engine, main hydraulic pump, transmission, and final drive—is available upon agreement.

A:

Bulldozers are heavy-duty machines; depending on their size and weight, we employ the following safe and cost-effective shipping solutions:

Flat Rack Container: Suitable for small to medium-sized bulldozers; they can be loaded as complete units or with the blade removed.

Ro-Ro (Roll-on/Roll-off) Ship: Equipment is driven directly onto and off the vessel. Transport takes place entirely within the cargo hold, offering protection against moisture and rust, as well as the highest level of safety.

Breakbulk Ship: Suitable for bulk shipments of bulldozers or for ultra-heavy mining bulldozers (e.g., those exceeding 320 horsepower).

Containerized Transport (40HQ): Certain small to medium-sized models can be loaded into 40-foot High Cube containers after the removal of the cab, track frames, and blade, significantly reducing shipping costs.

A:

Depending on operational requirements, the following attachments can be installed on the rear of a bulldozer:

Single-Shank Ripper: Suitable for breaking up hard rock, frozen ground, or damaged pavement.

Multi-Shank Ripper: Suitable for excavating soil and shale of moderate hardness.

Winch: Suitable for forestry operations, field recovery, and towing heavy loads.

Drawbar: Used for towing other unpowered construction equipment or trailers.

A:

We can configure the optimal machine based on your specific working environment:

Machine Versions: Available in Standard (general earthmoving), Wetland/LGP (swampy and soft terrain), Desert (high-temperature and dust-resistant), and Sanitation (landfill) versions.

Blade Types: Options include the Straight-Tilt Blade (high digging force; suitable for hard soil and rock), Angle Blade (adjustable angle; suitable for road construction and trench backfilling), or Semi-U Blade (high capacity; suitable for high-volume dozing).

A:

Yes, we guarantee that all bulldozers we supply are 100% brand-new, original equipment. They undergo rigorous factory quality inspections prior to shipment and come with the original manufacturer's certificate of conformity, factory inspection report, and technical documentation.

A:

We supply brand-new bulldozers from globally renowned brands such as SHANTUI, SDLG, XCMG, SANY, and LIUGONG.
Our product lineup covers a full range of crawler bulldozers—from 80 hp to 900 hp and above—including light-duty municipal models, medium-duty general-purpose models (such as the popular 160 hp, 220 hp, and 320 hp units), and heavy-duty mining-grade models.
